• User Page: 3.5 - inch color touch LCD screen
• Running Noise: ≤60dB(A) (gear 8)
• Product weight: 2.1Kg±0.1Kg (including a battery)
• Internal Battery: 14.4V DC 8A Max, 6500mAh
• Battery Duration: Up to 3.5 hours (1 gear to run)
• Battery Charging Time: Up to 3.5 hours
Product Size L*w*h: 180mm*95mm*190mm
Warm-up Time: 3 minutes
Oxygen Concentration: adjust oxygen concentration according to doctor guidance
Maximum Recommended Flow: 1L/min (oxygen concentration 93±3, flow rate 8, oxygen concentration ≥ 90% (V/V))
Respiratory Rate: 10-40 BPM
Maximum Export Pressure: 140KPa土20%
Alternating current Power Supply: AC100-240V 50/60Hz 100VA
Suitable Working Environment For Equipment:
Suitable temperature : 5-40°℃c
Suitable humidity:10%~90%, noncondensable atmospheric
Pressure range : 670hPa-1060hPa
Transportation Request: Keep dry, be careful, don't reverse or sideways,don't roll
Air Environment Requirements: Equipment that cannot be used in the case of flammable anesthetic gas mixed with air or flammable anesthetic gas mixed with oxygen or nitrous oxide
